| PartZenbakia | HV121X02-100 |
| Marka | HYDIS |
| Tamaina | 12.1 |
| Aplikazio | IA |
| Ebazpena | 1024×768 |
| Konposizioa | CELL |
| Distira | 0 |
| CR | 450:1 |
| Koloreak | 262K |
| Atzeko argia | No B/L |
| Interfazea | LVDS |
| panel marka | BOE HYDIS |
| panel eredua | HV121X02-100 |
| panel mota | a-Si TFT-LCD , CELL |
| panelaren tamaina | 12.1 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | AFFS, Normally Black, Transmissive |
| eremu aktiboa | 245.76×184.32 mm |
| azalera | Glare (Haze 0%), Antireflection |
| transmisibitatea | 5.91% (Typ.)(with Polarizer) |
| kontraste-erlazioa | 450:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193140% |
| erantzun denbora | 32 (Typ.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | LVDS (1 ch, 6-bit), 20 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
