| PartZenbakia | LQ085Y3DG18 |
| Marka | SHARP |
| Tamaina | 8.5 |
| Aplikazio | IA |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 450:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LQ085Y3DG18 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.5 inch |
| ebazpena | 800×480(RGB) , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 184.8×110.88 mm |
| eskema | 222.7×133.6×10.5 mm |
| azalera | Antiglare |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 450:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 8/21 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | CMOS (1 ch, 6-bit), 50 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
