| PartZenbakia | HV070WS1-100 |
| Marka | HYDIS |
| Tamaina | 7.0 |
| Aplikazio | MP4 |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | HYDIS |
| panel eredua | HV070WS1-100 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | HFFS, Normally Black, Transmissive |
| eremu aktiboa | 153.6×90 mm |
| eskema | 164.05×100.86 mm |
| azalera | |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 5S4PWLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 8-bit), 31 pins |
| sarrerako tentsioa | 3.7V (Typ.) |
| aplikazio | MP4 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| HV070WS1-100 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-101 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-1E1 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-1E2 | HYDIS | 7.0 | 1024×600 |
| HV070WSA-100 | BOE | 7.0 | 1024×600 |
| HV070WX2-100 | HYDIS | 7.0 | 800×1280 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| LMS700KF01-001 | Samsung | 7.0 | 800×480 |
| CLAA070LC0DCW | CPT | 7.0 | 800×480 |
| CLAA070NC0DCT | CPT | 7.0 | 1024×600 |
| HJ070NA-13A | Innolux | 7.0 | 1024×600 |
| HJ070NA-13D | Innolux | 7.0 | 1024×600 |
| HSD070PFW3-D00 | HannStar | 7.0 | 1024×600 |
| LB070WV4-TJ01 | LG Display | 7.0 | 800×480 |
| LMS700KF21 | Samsung | 7.0 | 800×480 |
| LTG430WQ-F02 | Samsung | 4.3 | 480×272 |
| LTM07C382 | TOSHIBA | 7.0 | 1024×600 |
| LTP700WV-F01 | Samsung | 7.0 | 800×480 |
