| PartZenbakia | HSD100PXN1-A00-C40 |
| Marka | HannStar |
| Tamaina | 10.0 |
| Aplikazio | PAD |
| Ebazpena | 1024×768 |
| Konposizioa | Assembly |
| Distira | 180 |
| CR | 600:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | HannStar |
| panel eredua | HSD100PXN1-A00-C40 |
| panel mota | a-Si TFT-LCD , Assembly |
| panelaren tamaina | 10.0 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| eremu aktiboa | 202.752×152.064 mm |
| eskema | 243.8×190.8×7.4 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 180 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193150% |
| ikuspegi angelua | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | LVDS (1 ch, 6-bit), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| BP082WX1-100 | BOE | 8.2 | 1280×800 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC3 | LG Display | 9.7 | 2048×1536 |
| LPM070W425D | JDI | 7.0 | 1200×1920 |
| LTL089CL02-001 | Samsung | 8.9 | 1920×1200 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| TPF0702002N | JDI | 7.0 | 1200×1920 |
