| PartZenbakia | LB070WV1-TD01 |
| Marka | LG Display |
| Tamaina | 7.0 |
| Aplikazio | CNS |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 600 |
| CR | |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | LG.Philips LCD |
| panel eredua | LB070WV1-TD01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 7.0 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 152.4×91.44 mm |
| eskema | 170×109.6×17.3 mm |
| azalera | Antiglare |
| distira | 600 cd/m² (Min.) |
| kontraste-erlazioa | |
| bistaratzeko koloreak | 262K (6-bit), CIE193145% |
| erantzun denbora | 10/40 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFLWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3V (Typ.)(VCC) |
| aplikazio | CNS |
