| PartZenbakia | CLAA070WQ62 XG |
| Marka | CPT |
| Tamaina | 7.0 |
| Aplikazio | Pad & Tablet |
| Ebazpena | 800×1280 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| marka | CPT |
| diagonalaren tamaina | 7.0 inch |
| pixel formatua | 800(RGB)×1280 [WXGA] 215PPI |
| eremu aktiboa | 94.2(H)×150.72(V) mm |
| bezela eremua | - |
| luminantzia | 350 cd/m² (Typ.) |
| ikusi norabidea | Symmetry |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| euskarria kolorea | 16.7M 70% NTSC |
| pisua | - |
| fotograma-tasa | 60Hz |
| interfaze mota | MIPI (4 data lanes) , 39 pins FPC |
| energia hornidura | 1.8/3.3/15/-10V (Typ.)(VDDI/VCI/VGH/VGL) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| eredua | CLAA070WQ62 XG |
| mota | a-Si TFT-LCD , LCM |
| konfigurazioa | RGB Vertical Stripe |
| eskema dim. | 99.6(H)×161.62(V) ×4.05(D) mm |
| tratamendua | Hard coating |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| funtzionamendu modua | FFS, Normally Black, Transmissive |
| argi iturria | WLED [3S6P] , 15K hours , W/O Driver |
| entzat diseinatua | Pad & Tablet |
| ukipen-panela | On-Cell Touch |
