| PartZenbakia | AT101WSM-N11-58P0 |
| Marka | BOE |
| Tamaina | 10.1 |
| Aplikazio | Automotive Display |
| Ebazpena | 1024×600 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | BOE |
| eredua | AT101WSM-N11-58P0 |
| diagonalaren tamaina | 10.1 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1024(RGB)×600 [WSVGA] 117PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 222.72(H)×125.28(V) mm |
| eskema dim. | 235(H)×144.9(V) ×5.44(D) mm |
| bezela eremua | 226(H)×128.6(V) mm |
| tratamendua | Antiglare, Hard coating (3H) |
| luminantzia | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) (TM) |
| ikusi norabidea | - |
| erantzun denbora | 25 (Typ.)(Tr+Tf) |
| ikuspegi angelua | 80/80/60/70 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 262K/16.7M 50% NTSC |
| argi iturria | WLED [3S14P] , 20K hours , W/O Driver |
| pisua | 300g (Max.) |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| energia hornidura | 3.3/11/21/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
