| PartZenbakia | P101KDA-AP1 |
| Marka | Innolux |
| Tamaina | 10.1 |
| Aplikazio | PAD |
| Ebazpena | 1200×1920 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | INNOLUX |
| panel eredua | P101KDA-AP1 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1200(RGB)×1920 , WUXGA |
| bistaratzeko modua | AAS, Normally Black, Transmissive |
| eremu aktiboa | 135.36×216.576 mm |
| eskema | 143×227.93×4.3 mm |
| azalera | Glare (Haze 0%), Hard coating (3H) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193170% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 stringsWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 45 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| LP101WH1-TLA1 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB2 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| LP101WS1-TLB3 | LG Display | 10.1 | 1024×576 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-W14 | Samsung | 10.1 | 1280×800 |
| M101NWT2 R2 | IVO | 10.1 | 1024×600 |
| P101KDA-AP1 | Innolux | 10.1 | 1200×1920 |
| BP101WX1-300 | BOE | 10.1 | 1280×800 |
| HT12X21-220 | HYDIS | 12.1 | 1024×768 |
| HX121WX1-100 | HYDIS | 12.1 | 1280×800 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LP097QX2-SPAV | LG Display | 9.7 | 1536×2048 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| LPM089A001A | JDI | 8.9 | 2560×1600 |
| LTL101DL03-T01 | Samsung | 10.1 | 2560×1600 |
| Q070LRE-LB1 | Innolux | 7.0 | 1024×600 |
| VVX07H005A10 | Panasonic | 7.0 | 800×1280 |
