| PartZenbakia | AT070WSM-NW2 |
| Marka | BOE |
| Tamaina | 7.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 1024×600 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | |
| marka | BOE |
| eredua | AT070WSM-NW2 |
| diagonalaren tamaina | 7.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1024(RGB)×600 [WSVGA] 170PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 154.214(H)×85.92(V) mm |
| eskema dim. | - |
| luminantzia | - |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikusi norabidea | - |
| erantzun denbora | 25 (Typ.)(Tr+Tf) |
| ikuspegi angelua | 80/80/60/70 (Typ.)(CR≥10) |
| funtzionamendu modua | TN, Normally White, Transmissive |
| euskarria kolorea | 262K/16.7M 50% NTSC |
| argi iturria | WLED |
| pisua | - |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| BP070HD1-100 | BOE | 7.0 | 720×1280 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| CLAA070LC0ACW | CPT | 7.0 | 800×480 |
| CLAA070LC0CCW | CPT | 7.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| ZJ070NA-01P | Innolux | 7.0 | 1024×600 |
