| PartZenbakia | AM-1024600ITZQW-T00H |
| Marka | AMPIRE |
| Tamaina | 10.1 |
| Aplikazio | Industrial |
| Ebazpena | 1024×600 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| fabrikatzailea | AMPIRE |
| pantailaren tamaina | 10.1 inch |
| pixel-zenbakia | 1024(RGB)×600 (WSVGA) 117PPI |
| eremu aktiboa (mm) | 222.72 × 125.28 (H×V) |
| bezela eremua (mm) | - |
| luminantzia | 465 cd/m² (Typ.) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| ikuspegi ona | Symmetry |
| kolore-sakonera | 262K/16.7M 70% NTSC |
| masa | - |
| freskatze tasa | 60Hz |
| seinale mota | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| tentsio-hornidura | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ereduaren izena | AM-1024600ITZQW-T00H |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 255 × 165.8 (H×V×D) |
| tratamendua | Antiglare, Hard coating |
| kontraste-erlazioa | 500 : 1 (Typ.) (TM) |
| erantzuna | 12/28 (Typ.)(Tr/Td) ms |
| lan egiteko modua | IPS, Normally Black, Transmissive |
| atzeko argia | WLED , 50K hours , No Driver |
| erabiltzen | Industrial |
| pantaila taktila | PCAP |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| LTN101AL01-F01 | Samsung | 10.1 | 1280×800 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| VVX10F002A00 | Panasonic | 10.1 | 1920×1200 |
