| PartZenbakia | AM-1024600DTZQW-TA6H |
| Marka | AMPIRE |
| Tamaina | 7.0 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1024×600 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | AMPIRE |
| eredua | AM-1024600DTZQW-TA6H |
| diagonalaren tamaina | 7.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1024(RGB)×600 [WSVGA] 170PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 154.221(H)×85.92(V) mm |
| eskema dim. | 164.9(H)×128(V) ×12.6(D) mm |
| luminantzia | 850 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 13/15 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | IPS, Normally Black, Transmissive |
| euskarria kolorea | 16.7M 58% NTSC |
| argi iturria | WLED , 50K hours , With LED Driver |
| pisua | - |
| entzat diseinatua | Industrial Outdoor High Brightness |
| fotograma-tasa | 60Hz |
| ukipen-panela | PCAP |
| interfaze mota | LVDS (1 ch, 8-bit) , 20 pins Connector |
| energia hornidura | 3.3V (Typ.) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
