| PartZenbakia | AM-1024600DTZQW-A6H |
| Marka | AMPIRE |
| Tamaina | 7.0 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 1024×600 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| fabrikatzailea | AMPIRE |
| ereduaren izena | AM-1024600DTZQW-A6H |
| pantailaren tamaina | 7.0 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 1024(RGB)×600 (WSVGA) 170PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 154.221 × 85.92 (H×V) |
| eskema (mm) | 164.9 × 100 (H×V×D) |
| bezela eremua (mm) | 158 × 89.7 (H×V) |
| tratamendua | Antiglare |
| luminantzia | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| erantzuna | 13/15 (Typ.)(Tr/Td) ms |
| ikuspegi ona | Symmetry |
| lan egiteko modua | IPS, Normally Black, Transmissive |
| kolore-sakonera | 16.7M |
| atzeko argia | WLED , 50K hours , With LED Driver |
| masa | - |
| erabiltzen | Industrial Outdoor High Brightness |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| seinale mota | LVDS (1 ch, 8-bit) , 20 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
