| PartZenbakia | AC070MR11 |
| Marka | Mitsubishi |
| Tamaina | 7.0 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 800×480 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 2 |
| Interfazea | LVDS |
| panel marka | Mitsubishi |
| panelaren tamaina | 7.0" |
| ebazpena | 800(RGB)×480, WVGA, 133PPI |
| bistaratzeko eremua | 152.4(W)×91.44(H) mm |
| eskema tamaina | 169.8(W)×109.7(H) ×9.3(D) mm |
| distira | 1000 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 262K/16.7M |
| maiztasuna | 60Hz |
| panelaren pisua | 185g (Typ.) |
| seinale interfazea | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
| panel eredua | AC070MR11 |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 154.4(W)×93.44(H) mm |
| azalera | Antiglare, Hard coating (3H) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| bistaratzeko modua | SWV, Normally Black, Transmissive |
| erantzun denbora | 15/15 (Typ.)(Tr/Td) |
| lanpara mota | 2 strings WLED , 50K hours , Without Driver |
| pantaila taktila | Without |
| aplikazio | Industrial Outdoor High Brightness |
