| PartZenbakia | AA084XB01 |
| Marka | Mitsubishi |
| Tamaina | 8.4 |
| Aplikazio | IA |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 500 |
| CR | 600:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | Mitsubishi |
| panel eredua | AA084XB01 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.4 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 170.496×127.872 mm |
| eskema | 199.5×149 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 8-bit), CIE193140% |
| erantzun denbora | 4/12(Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 stringsWLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 6/8-bit), 20 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| AA084SB01 | Mitsubishi | 8.4 | 800×600 |
| AA084SB11 | Mitsubishi | 8.4 | 800×600 |
| AA084SC01 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084VB02 | Mitsubishi | 8.4 | 640×480 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| AA084VC05 | Mitsubishi | 8.4 | 640×480 |
| AA084XB01 | Mitsubishi | 8.4 | 1024×768 |
| AA084XE11 | Mitsubishi | 8.4 | 1024×768 |
| AA141TC01 | Mitsubishi | 14.1 | 1280×800 |
| AA150XN09 | Mitsubishi | 15.0 | 1024×768 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| LM32015T | SHARP | 5.7 | 320×240 |
| LQ084S3LG02 | SHARP | 8.4 | 800×600 |
| LQ12X12 | SHARP | 12.1 | 1024×768 |
| LQ190N1LW01 | SHARP | 19.0 | 1680×1050 |
| MD400F640PD5 | Panasonic | 9.8 | 640×400 |
| NL8048BC24-14NH | NLT | 9.0 | 800×480 |
| TX31D32VM2AAA | KOE | 12.1 | 800×600 |
