| PartZenbakia | LQ12X12 |
| Marka | SHARP |
| Tamaina | 12.1 |
| Aplikazio | IA |
| Ebazpena | 1024×768 |
| Konposizioa | LCM |
| Distira | 150 |
| CR | 100:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LQ12X12 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 12.1 inch |
| ebazpena | 1024(RGB)×768 , XGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 245.76×184.32 mm |
| eskema | 283×215.6×17 mm |
| azalera | Antiglare, Hard coating (2H) |
| distira | 150 cd/m² (Typ.) |
| kontraste-erlazioa | 100:1 (Min.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 30/50 (Typ.)(Tr/Td) |
| ikuspegi angelua | 35/35/10/30 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFLWithout Driver |
| seinale interfazea | Parallel RGB (2 ch, 6-bit), 50 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | IA |
