| PartZenbakia | TM035KDH04 |
| Marka | Tianma |
| Tamaina | 3.5 |
| Aplikazio | DSC |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 420 |
| CR | 500:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | Parallel/Serial |
| panel marka | TIANMA |
| panel eredua | TM035KDH04 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 70.08×52.56 mm |
| eskema | 76.9×63.9×3 mm |
| azalera | Clear |
| distira | 420 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Dithering), CIE193150% |
| erantzun denbora | 25 (Typ.)(Tr+Td) |
| ikuspegi angelua | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 6S1PWLEDWithout Driver |
| seinale interfazea | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | DSC |
