| PartZenbakia | UMSH-8065MD-11T |
| Marka | Other |
| Tamaina | 3.5 |
| Aplikazio | IA |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 700 |
| CR | 800:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | Parallel/Serial |
| panel marka | URT |
| panel eredua | UMSH-8065MD-11T |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 70.08×52.56 mm |
| eskema | 76.9×63.9×3.5 mm |
| azalera | |
| distira | 700 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 15/35 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/45/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 70Hz |
| lanpara mota | 5S2PWLEDWithout Driver |
| seinale interfazea | Digital RGB (8/24-bit) + SPI, CCIR601/656, 50 pins |
| sarrerako tentsioa | 3.3/3.3V (Typ.)(VCI/VDDIO) |
| aplikazio | IA |
