| PartZenbakia | A035VL01 V6 |
| Marka | AUO |
| Tamaina | 3.5 |
| Aplikazio | DSC |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 315 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | AUO |
| panel eredua | A035VL01 V6 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 3.5 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 75.6×45.36 mm |
| eskema | 86.1×51.66 mm |
| azalera | Glare (Haze 0%) |
| distira | 315 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 15/30 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 5S1PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| sarrerako tentsioa | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| aplikazio | DSC |
| 35HVE0H | SII | 3.5 | 320×480 |
| A035VL01 V0 | AUO | 3.5 | 800×480 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| A035VL01 V6 | AUO | 3.5 | 800×480 |
| LQ035Q3DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| PW035XU1 | E Ink | 3.5 | 320×234 |
| TD035STEB1 | TPO | 3.5 | 240×320 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035PDH53 | Tianma | 3.5 | 320×480 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| A015AN03 V0 | AUO | 1.46 | 280×220 |
| A025DN01 V3 | AUO | 2.5 | 320×240 |
| A030DN04 V0 | AUO | 3.0 | 320×240 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
| PA025XSC | E Ink | 2.5 | 480×234 |
| PD035OX1 | E Ink | 3.5 | 320×234 |
| TM027CDH04 | Tianma | 2.7 | 320×240 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
