| PartZenbakia | A025DN01 V9 |
| Marka | AUO |
| Tamaina | 2.5 |
| Aplikazio | DSC |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 300:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | Serial RGB |
| panel marka | AUO |
| panel eredua | A025DN01 V9 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 2.5 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 49.92×37.44 mm |
| eskema | 59.63×43.7×2.9 mm |
| azalera | Hard coating |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 300:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 15/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 1 pcsWLED |
| seinale interfazea | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| sarrerako tentsioa | 3.3/15/-10V (VDD/VGH/VGL) |
| aplikazio | DSC |
