| PartZenbakia | A015AN03 |
| Marka | AUO |
| Tamaina | 1.46 |
| Aplikazio | DSC |
| Ebazpena | 280×220 |
| Konposizioa | LCM |
| Distira | 200 |
| CR | 150:1 |
| Koloreak | Full color |
| Atzeko argia | WLED |
| Interfazea | Analog |
| panel marka | AU Optronics |
| panel eredua | A015AN03 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 1.46 inch |
| ebazpena | 280×220 |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 29.54×22.22 mm |
| eskema | 40.1×34.6×4.2 mm |
| azalera | Hard coating (3H) |
| distira | 200 cd/m² (Typ.) |
| kontraste-erlazioa | 150:1 (Typ.) |
| bistaratzeko koloreak | Full color |
| erantzun denbora | 25/30 (Typ.)(Tr/Td) |
| ikuspegi angelua | 45/45/10/30 (Min.)(CR≥10)(L/R/U/D) |
| lanpara mota | 2S1PWLEDWithout Driver |
| seinale interfazea | TFT Specific Analog RGB, 26 pins |
| sarrerako tentsioa | 5.0/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikazio | DSC |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| A015AN03 V0 | AUO | 1.46 | 280×220 |
| A027DN03 V2 | AUO | 2.7 | 320×240 |
| A030DN01 V0 | AUO | 3.0 | 320×240 |
| LQ027A3DA01 | SHARP | 2.7 | 320×240 |
| PD024OX4 | E Ink | 2.4 | 480×234 |
| TD024THEB5 | TPO | 2.4 | 480×240 |
| TM027CDH12 | Tianma | 2.7 | 320×240 |
| TM035KDH03 | Tianma | 3.5 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
