| PartZenbakia | A025DL02 V5 |
| Marka | AUO |
| Tamaina | 2.5 |
| Aplikazio | DSC |
| Ebazpena | 320×240 |
| Konposizioa | LCM |
| Distira | 400 |
| CR | 300:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | Serial RGB |
| panel marka | AUO |
| panel eredua | A025DL02 V5 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 2.5 inch |
| ebazpena | 320(RGB)×240 , QVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 50.4×37.8 mm |
| eskema | 60.73×45.07 mm |
| azalera | Hard coating (3H) |
| distira | 400 cd/m² (Typ.) |
| kontraste-erlazioa | 300:1 (Min.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 15/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 55/55/45/70 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 3S1PWLED |
| seinale interfazea | Serial RGB (8-bit) + SPI, CCIR656, 39 pins |
| sarrerako tentsioa | 3.3/3.3 (Typ.)(VDC/VDCI) |
| rohs: | |
| aplikazio | DSC |
