| PartZenbakia | LQ043T1DG28 |
| Marka | SHARP |
| Tamaina | 4.3 |
| Aplikazio | HHP |
| Ebazpena | 480×272 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LQ043T1DG28 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 4.3 inch |
| ebazpena | 480×272(RGB) , WQVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 95.04×53.856 mm |
| eskema | 105.5×67.2×4.45 mm |
| azalera | Antiglare, Hard coating (2H) |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 22/8 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/55/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 9S1PWLEDWithout Driver |
| seinale interfazea | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| sarrerako tentsioa | 3.3/3.3V (Typ.)(IOVCC/VCC) |
| aplikazio | HHP |
