| PartZenbakia | AA190EA01 |
| Marka | Mitsubishi |
| Tamaina | 19.0 |
| Aplikazio | IA |
| Ebazpena | 1280×1024 |
| Konposizioa | LCM |
| Distira | 1500 |
| CR | 800:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | Mitsubishi |
| panel eredua | AA190EA01 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 19.0 inch |
| ebazpena | 1280(RGB)×1024 , SXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 376.32×301.056 mm |
| eskema | 404.2×330×15.4 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 1500 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| erantzun denbora | 4/12 (Typ.)(Tr/Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 strings × 2CNWLEDWithout Driver |
| seinale interfazea | LVDS (2 ch, 6/8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | IA |
