| PartZenbakia | UG-5664ALBDF01 |
| Marka | WiseChip |
| Tamaina | 2.8 |
| Aplikazio | IA |
| Ebazpena | 256×64 |
| Konposizioa | OLED |
| Distira | 80 |
| CR | 2000:1 |
| Koloreak | Mono(Blue) |
| Atzeko argia | self |
| Interfazea | CPU/SPI |
| panel marka | Univision |
| panel eredua | UG-5664ALBDF01 |
| panel mota | PM-OLED , OLED |
| panelaren tamaina | 2.8 inch |
| ebazpena | 256×64 |
| eremu aktiboa | 69.104×17.264 mm |
| eskema | 84×25.8×2.1 mm |
| azalera | |
| distira | 80 cd/m² (Typ.) |
| kontraste-erlazioa | 2000 : 1 (Typ.) |
| bistaratzeko koloreak | Mono(Blue) |
| ikuspegi angelua | 80/80/80/80 (Min.)(L/R/U/D) |
| gidariaren ic | COF Built-in SSD1322 |
| seinale interfazea | 8-bit 6800/8080 parallel, 4-wire SPI, 30 pins |
| sarrerako tentsioa | 2.8/12V (Typ.)(VCI/VCC) |
| rohs: | |
| aplikazio | IA |
