| PartZenbakia | TX20D33VM2BAC |
| Marka | KOE |
| Tamaina | 8.0 |
| Aplikazio | Industrial |
| Ebazpena | 800×480 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 600:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | CMOS |
| fabrikatzailea | KOE |
| pantailaren tamaina | 8.0 inch |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 116PPI |
| eremu aktiboa (mm) | 174 × 104.4 (H×V) |
| bezela eremua (mm) | 187.0 × 108.4 (H×V) |
| luminantzia | - |
| ikuspegi angelua | 80/80/60/80 (Typ.)(CR≥10) |
| ikuspegi ona | 6 o'clock |
| kolore-sakonera | 262K |
| masa | 160g |
| freskatze tasa | 60Hz |
| seinale mota | CMOS (1 ch, 6-bit) , 40 pins Connector |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| ereduaren izena | TX20D33VM2BAC |
| pantaila mota | LCM , a-Si TFT-LCD |
| antolamendua | RGB Vertical Stripe |
| eskema (mm) | 189 × 120 × 8 (H×V×D) |
| tratamendua | - |
| kontraste-erlazioa | 600 : 1 (Typ.) (TM) |
| erantzuna | 20 (Typ.)(Tr+Td) ms |
| lan egiteko modua | TN, Normally White, Transmissive |
| atzeko argia | WLED , 50K hours , No Driver |
| erabiltzen | Industrial |
| pantaila taktila | Without |
