| PartZenbakia | TX20D207VM0AAA |
| Marka | KOE |
| Tamaina | 8.0 |
| Aplikazio | Industrial Automotiv |
| Ebazpena | 1280×768 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 1400:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | KOE |
| panel eredua | TX20D207VM0AAA |
| panelaren tamaina | 8.0" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 1280(RGB)×768, WXGA, 186PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 173.952(W)×104.371(H) mm |
| bezela irekidura | 177.0(W)×107.4(H) mm |
| eskema tamaina | 189.5(W)×119.4(H) ×12.1(D) mm |
| azalera | - |
| distira | 1200 cd/m² (Typ.) |
| kontraste-erlazioa | 1400:1 (Typ.) (TM) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| bistaratzeko modua | IPS, Normally Black, Transmissive |
| ikuspegirik onena | Symmetry |
| erantzun denbora | 19 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 16.7M 70% NTSC |
| lanpara mota | WLED , 70K hours , With LED Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | 254g (Typ.) |
| aplikazio | Industrial Automotive Display |
| seinale interfazea | LVDS (1 ch, 8-bit) , 20 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| BP080WX1-100 | BOE | 8.0 | 1280×800 |
| L5F30614T64 | SANYO | 8.0 | 800×480 |
| LA080WV3-SD01 | LG Display | 8.0 | 800×480 |
| LQ080V3DG01 | SHARP | 8.0 | 640×480 |
| LQ080Y5DW03 | SHARP | 8.0 | 800×480 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| N080JCE-G41 | Innolux | 8.0 | 1200×1920 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| TM080XPH01 | Tianma | 8.0 | 1280×768 |
