| PartZenbakia | TM104TDGP10 |
| Marka | TIANMA |
| Tamaina | 10.4 |
| Aplikazio | Industrial |
| Ebazpena | 1024×768 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 1200:1 |
| Koloreak | 262K/16.7M |
| Atzeko argia | 8S4P |
| Interfazea | LVDS |
| panel marka | TIANMA |
| panelaren tamaina | 10.4" |
| ebazpena | 1024(RGB)×768, XGA, 123PPI |
| bistaratzeko eremua | 210.432(W)×157.824(H) mm |
| eskema tamaina | 230(W)×175.8(H) ×9.06(D) mm |
| distira | 450 cd/m² (Typ.) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 262K/16.7M 50% NTSC |
| maiztasuna | 60Hz |
| panelaren pisua | 430g (Typ.) |
| seinale interfazea | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel eredua | TM104TDGP10 |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 213.43(W)×160.82(H) mm |
| azalera | Antiglare |
| kontraste-erlazioa | 1200:1 (Typ.) (TM) |
| bistaratzeko modua | SFT, Normally Black, Transmissive |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| lanpara mota | 8S4P WLED , With LED Driver |
| pantaila taktila | Without |
| aplikazio | Industrial |
| LB104S01-TL02 | LG Display | 10.4 | 800×600 |
| LQ104V1DW02 | SHARP | 10.4 | 640×480 |
| LQ10D131 | SHARP | 10.4 | 640×480 |
| LTM10C348F | TOSHIBA | 10.4 | 800×600 |
| TM104QDSG09 | Tianma | 10.4 | 640×480 |
| TM104SBH01 | Tianma | 10.4 | 800×600 |
| TM104SCH02 | Tianma | 10.4 | 800×600 |
| TM104SDH01 | Tianma | 10.4 | 800×600 |
| TM104SDH02 | Tianma | 10.4 | 800×600 |
| TM104SDHG30 | Tianma | 10.4 | 800×600 |
