| PartZenbakia | TM070RDHG34 |
| Marka | TIANMA |
| Tamaina | 7.0 |
| Aplikazio | Industrial Outdoor H |
| Ebazpena | 800×480 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | 3S8P |
| Interfazea | |
| fabrikatzailea | TIANMA |
| ereduaren izena | TM070RDHG34 |
| pantailaren tamaina | 7.0 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 800(RGB)×480 (WVGA) 134PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 154.08 × 85.92 (H×V) |
| eskema (mm) | 164.9 × 100 × 6 (H×V×D) |
| bezela eremua (mm) | 157.08 × 89.39 (H×V) |
| tratamendua | Antiglare |
| luminantzia | 1000 cd/m² (Typ.) |
| kontraste-erlazioa | 800 : 1 (Typ.) (TM) |
| ikuspegi angelua | 70/70/60/70 (Typ.)(CR≥10) |
| erantzuna | 25 (Typ.)(Tr+Td) ms |
| ikuspegi ona | 6 o'clock |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 16.7M 50% NTSC |
| atzeko argia | 3S8P WLED , 50K hours , No Driver |
| masa | TBD |
| erabiltzen | Industrial Outdoor High Brightness Automotive Display |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
