| PartZenbakia | TM050RDH03-00 |
| Marka | TIANMA |
| Tamaina | 5.0 |
| Aplikazio | Industrial Portable |
| Ebazpena | 800×480 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 600:1 |
| Koloreak | 16.7M |
| Atzeko argia | 7S2P |
| Interfazea | Parallel |
| panel marka | TIANMA |
| panel eredua | TM050RDH03-00 0 Compatible |
| panelaren tamaina | 5.0" |
| panel mota | a-Si TFT-LCD, LCM |
| ebazpena | 800(RGB)×480, WVGA, 188PPI |
| pixel formatua | RGB Vertical Stripe |
| bistaratzeko eremua | 108(W)×64.8(H) mm |
| bezela irekidura | 111.1(W)×67.9(H) mm |
| eskema tamaina | 120.7(W)×75.8(H) ×3.1(D) mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 600:1 (Typ.) (TM) |
| ikuspegi angelua | 70/70/50/70 (Typ.)(CR≥10) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| ikuspegirik onena | 12 o'clock |
| erantzun denbora | 20 (Typ.)(Tr+Td) |
| bistaratzeko koloreak | 16.7M 50% NTSC |
| lanpara mota | 7S2P WLED , 20K hours , Without Driver |
| maiztasuna | 60Hz |
| pantaila taktila | Without |
| panelaren pisua | TBD |
| aplikazio | Industrial Portable Navigation MID UMPC MP3 PMP |
| seinale interfazea | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| sarrerako tentsioa | 3.3V (Typ.) |
| ingurunea | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
