| PartZenbakia | LTM030DH60 |
| Marka | TOSHIBA |
| Tamaina | 3.0 |
| Aplikazio | MPH |
| Ebazpena | 240×427 |
| Konposizioa | CELL |
| Distira | 0 |
| CR | 800:1 |
| Koloreak | 262K |
| Atzeko argia | No B/L |
| Interfazea | M-CMADS |
| panel marka | TOSHIBA |
| panel eredua | LTM030DH60 |
| panel mota | LTPS TFT-LCD , CELL |
| panelaren tamaina | 3.0 inch |
| ebazpena | 240(RGB)×427 |
| bistaratzeko modua | TN, Normally White, Transflective |
| eremu aktiboa | 36.72×65.33 mm |
| eskema | 40.52×72.63 mm |
| azalera | |
| beiraren sakonera | 0.10+0.20 mm |
| transmisibitatea | 5.4% (Typ.)(with Polarizer) |
| kontraste-erlazioa | 800:1 (Typ.)(Transmissive)4:1 (Typ.)(Reflective) |
| bistaratzeko koloreak | 262K , CIE193164% |
| erantzun denbora | 45/45 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/70/70 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | M-CMADS + SPI, 22 pins |
| sarrerako tentsioa | 2.8/1.8V (Typ.)(VCC/VDDIO) |
| aplikazio | MPH |
