| PartZenbakia | TM035HDZP04 |
| Marka | TIANMA |
| Tamaina | 3.5 |
| Aplikazio | Automotive Display |
| Ebazpena | 240×320 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | |
| panel marka | TIANMA |
| panelaren tamaina | 3.5" |
| ebazpena | 240(RGB)×320, QVGA, 114PPI |
| bistaratzeko eremua | 53.28(W)×71.04(H) mm |
| distira | - |
| ikuspegi angelua | 88/88/88/88 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 262K |
| maiztasuna | 60Hz |
| pisua | - |
| panel eredua | TM035HDZP04 |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | 58.28(W)×74.04(H) mm |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| bistaratzeko modua | SFT, Normally Black, Transmissive |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| lanpara mota | WLED , 10K hours , Without Driver |
| pantaila taktila | - |
| aplikazio | Automotive Display |
