| PartZenbakia | TCG121WXLPAPNN-AN20 |
| Marka | Kyocera |
| Tamaina | 12.1 |
| Aplikazio | IA |
| Ebazpena | 1280×800 |
| Konposizioa | LCM |
| Distira | 500 |
| CR | 750:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | Kyocera |
| panel eredua | TCG121WXLPAPNN-AN20 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 12.1 inch |
| ebazpena | 1280(RGB)×800 , WXGA |
| bistaratzeko modua | AWV, Normally Black, Transmissive |
| eremu aktiboa | 261.12×163.2 mm |
| eskema | 277.7×182.5 mm |
| azalera | Antiglare |
| distira | 500 cd/m² (Typ.) |
| kontraste-erlazioa | 750:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (6-bit + Hi-FRC) |
| erantzun denbora | 18/12 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDEmbedded (LED Driver) |
| seinale interfazea | LVDS (1 ch, 8-bit), 20 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | IA |
