| PartZenbakia | STCG057QVLAD-G00 |
| Marka | Kyocera |
| Tamaina | 5.7 |
| Aplikazio | Industrial |
| Ebazpena | 320×240 |
| Konposizioa | LCM , a-Si TFT-LCD |
| Distira | |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | Parallel |
| fabrikatzailea | Kyocera |
| ereduaren izena | STCG057QVLAD-G00 |
| pantailaren tamaina | 5.7 inch |
| pantaila mota | LCM , a-Si TFT-LCD |
| pixel-zenbakia | 320(RGB)×240 (QVGA) 70PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 115.2 × 86.4 (H×V) |
| eskema (mm) | - |
| bezela eremua (mm) | - |
| tratamendua | Glare (Haze 0%) |
| luminantzia | - |
| kontraste-erlazioa | 500 : 1 (Typ.) (TM) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥5) |
| erantzuna | 10/25 (Typ.)(Tr/Td) ms |
| ikuspegi ona | - |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 262K |
| atzeko argia | WLED |
| masa | - |
| erabiltzen | Industrial |
| freskatze tasa | - |
| pantaila taktila | 4-wire Resistive Touch |
| seinale mota | Parallel RGB (1 ch, 6-bit) |
| tentsio-hornidura | 3.3V (Typ.) |
| gehienez. balorazioak | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
