| PartZenbakia | NL6448AC33-A1D |
| Marka | NLT |
| Tamaina | 10.4 |
| Aplikazio | Industrial |
| Ebazpena | 640×480 |
| Konposizioa | LCM, a-Si TFT-LCD |
| Distira | |
| CR | 900:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | |
| fabrikatzailea | NLT |
| ereduaren izena | NL6448AC33-A1D |
| pantailaren tamaina | 10.4 inch |
| pantaila mota | LCM, a-Si TFT-LCD |
| pixel-zenbakia | 640(RGB)×480 (VGA) 76PPI |
| antolamendua | RGB Vertical Stripe |
| eremu aktiboa (mm) | 211.2 × 158.4 (H×V) |
| eskema (mm) | 227.3 × 177.5 × 9.8 (H×V×D) |
| bezela eremua (mm) | - |
| tratamendua | Antiglare |
| luminantzia | 370 cd/m² (Typ.) |
| kontraste-erlazioa | 900 : 1 (Typ.) (TM) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| erantzuna | 18 (Typ.)(Tr+Td) ms |
| ikuspegi ona | - |
| lan egiteko modua | TN, Normally White, Transmissive |
| kolore-sakonera | 262K |
| atzeko argia | WLED , 100K hours , With LED Driver |
| masa | 380g (Max.) |
| erabiltzen | Industrial |
| freskatze tasa | 60Hz |
| pantaila taktila | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| NL6448AC20-06 | NLT | 6.5 | 640×480 |
| NL6448AC30-09 | NLT | 9.4 | 640×480 |
| NL6448AC30-10 | NLT | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| NL6448AC33-05 | NLT | 10.4 | 640×480 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448AC33-24 | NLT | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
