| PartZenbakia | NL6448AC30-10 |
| Marka | NLT |
| Tamaina | 9.4 |
| Aplikazio | IA |
| Ebazpena | 640×480 |
| Konposizioa | LCM |
| Distira | 90 |
| CR | 110:1 |
| Koloreak | 4096 |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | NEC |
| panel eredua | NL6448AC30-10 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 9.4 inch |
| ebazpena | 640(RGB)×480 , VGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 192×144 mm |
| eskema | 259.5×179×12.5 mm |
| azalera | |
| distira | 90 cd/m² (Typ.) |
| kontraste-erlazioa | 110:1 (Typ.) |
| bistaratzeko koloreak | 4096 (4-bit), CIE193155% |
| erantzun denbora | 40 (Max.)(Tr+Td) |
| ikuspegi angelua | 45/45/25/25 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 1 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | CMOS (1 ch, 4-bit), 34 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | IA |
