| PartZenbakia | NL6448AC33-A0D |
| Marka | NLT |
| Tamaina | 10.4 |
| Aplikazio | Industrial |
| Ebazpena | 640×480 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 900:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | CMOS |
| panel marka | NLT |
| panelaren tamaina | 10.4" |
| ebazpena | 640(RGB)×480, VGA, 76PPI |
| bistaratzeko eremua | 211.2(W)×158.4(H) mm |
| eskema tamaina | 246.5(W)×179.4(H) ×10(D) mm |
| distira | 500 cd/m² (Typ.) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥10) |
| ikuspegirik onena | - |
| bistaratzeko koloreak | 262K 40% NTSC |
| maiztasuna | 60Hz |
| panelaren pisua | 390/435g (Typ./Max.) |
| seinale interfazea | CMOS (1 ch, 6-bit) , 31 pins Connector |
| sarrerako tentsioa | 3.3/5.0V (Typ.) |
| ingurunea | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| panel eredua | NL6448AC33-A0D |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | Antiglare, Hard coating (3H) |
| kontraste-erlazioa | 900:1 (Typ.) (TM) |
| bistaratzeko modua | TN, Normally White, Transmissive |
| erantzun denbora | 3/15 (Typ.)(Tr/Td) |
| lanpara mota | WLED , 100K hours , With LED Driver |
| pantaila taktila | Without |
| aplikazio | Industrial |
