| PartZenbakia | LTM170EI-A01 |
| Marka | Samsung |
| Tamaina | 17.0 |
| Aplikazio | DMPC |
| Ebazpena | 1280×1024 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 350:1 |
| Koloreak | 16.2M |
| Atzeko argia | CCFL |
| Interfazea | Analog |
| panel marka | SAMSUNG |
| panel eredua | LTM170EI-A01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.0 inch |
| ebazpena | 1280(RGB)×1024 , SXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 337.92×270.336 mm |
| eskema | 383.5×298.6×19.5 mm |
| azalera | Antiglare (Haze 25%), Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 350:1 (Typ.) |
| bistaratzeko koloreak | 16.2M (6-bit + FRC), CIE193165% |
| erantzun denbora | 5/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 75/75/65/60 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | Analog RGB, 27 pins |
| aplikazio | DMPC |
