| PartZenbakia | LTA120W1-T02 |
| Marka | Samsung |
| Tamaina | 12.0 |
| Aplikazio | DPF |
| Ebazpena | 800×480 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 300:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | TTL |
| panel marka | SAMSUNG |
| panel eredua | LTA120W1-T02 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 12.0 inch |
| ebazpena | 800(RGB)×480 , WVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 261.6×156.96 mm |
| eskema | 281.3×171.4 mm |
| azalera | |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 300:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | |
| ikuspegi angelua | |
| lanpara mota | 2 pcsCCFL |
| seinale interfazea | TTL (1 ch, 6-bit) |
| rohs: | |
| aplikazio | DPF |
