| PartZenbakia | AMS470GS16-1 |
| Marka | Samsung |
| Tamaina | 4.7 |
| Aplikazio | MPH |
| Ebazpena | 720×1280 |
| Konposizioa | Assembly |
| Distira | 300 |
| CR | 3400:1 |
| Koloreak | 16.7M |
| Atzeko argia | self |
| Interfazea | MIPI |
| panel marka | SAMSUNG |
| panel eredua | AMS470GS16-1 |
| panel mota | AM-OLED , Assembly |
| panelaren tamaina | 4.7 inch |
| ebazpena | 720RG(BG)×1280 , WXGA |
| eremu aktiboa | 57.96×103.04 mm |
| eskema | 66.36×131.8 mm |
| azalera | Hard coating |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 3400 : 1 (Min.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE1931110% |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| seinale interfazea | MIPI (4 data lanes), 44 pins |
| sarrerako tentsioa | 2.5/3.1/3.8V (VDD3/VCI/VBAT) |
| aplikazio | MPH |
