| PartZenbakia | ACX450AKN-7 |
| Marka | JDI |
| Tamaina | 5.0 |
| Aplikazio | MPH |
| Ebazpena | 1080×1920 |
| Konposizioa | LCM |
| Distira | 485 |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | JDI |
| panel eredua | ACX450AKN-7 |
| panel mota | LTPS TFT-LCD , LCM |
| panelaren tamaina | 5.0 inch |
| ebazpena | 1080(RGB)×1920 , FHD |
| bistaratzeko modua | Normally Black, Transmissive |
| eremu aktiboa | 61.884×110.016 mm |
| eskema | 64.284×118.8×1.58 mm |
| azalera | Hard coating (3H) |
| distira | 485 cd/m² (Typ.) |
| kontraste-erlazioa | 1000:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193171% |
| erantzun denbora | 35 (Max.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S2PWLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes), 31 pins |
| sarrerako tentsioa | +5.0/-5.0/1.8V (Typ.)(AVDD+/AVDD-/IOVDD) |
| aplikazio | MPH |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| A050VVN01.0 | AUO | 5.0 | 480×800 |
| ACX450AKN-7 | JDI | 5.0 | 1080×1920 |
| AM-800480-050D | Other | 5.0 | 800×480 |
| BTL507212-W746L | BOE | 5.0 | 720×1280 |
| ED050SC3 | E Ink | 5.0 | 800×600 |
| LD050WQ1-TD02 | LG Display | 5.0 | 480×272 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| LTG500QV-F03 | Samsung | 5.0 | 320×240 |
| PJ050IA-14A | Innolux | 5.0 | 720×1280 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| CLAF050LG41 TXX | CPT | 5.0 | 540×960 |
| CT022TN15 | Innolux | 2.2 | 176×220 |
| DX12D100VM0EAA | JDI | 4.7 | 720×1280 |
| LB020Q01-A1 | LG Display | 2.0 | 320×240 |
| LH400WV3-SD02 | LG Display | 4.0 | 480×800 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| OEL9M0039-G-E | Other | 1.5 | 128×128 |
| TM022GDH11 | Tianma | 2.2 | 176×220 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
