| PartZenbakia | LR043AC212 |
| Marka | Innolux |
| Tamaina | 4.3 |
| Aplikazio | PND |
| Ebazpena | 480×272 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 400:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | Parallel/Serial |
| panel marka | ChiHsin |
| panel eredua | LR043AC212 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 4.3 inch |
| ebazpena | 480(RGB)×272 , WQVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 95.04×53.856 mm |
| eskema | 105.5×67.2 mm |
| azalera | Antiglare |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 400:1 (Typ.) |
| bistaratzeko koloreak | 16.7M |
| erantzun denbora | 15/35 (Typ.)(Tr/Td) |
| ikuspegi angelua | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 7S1PWLEDWithout Driver |
| seinale interfazea | Digital RGB (8/24-bit), 60 pins |
| sarrerako tentsioa | 3/5.0V (Typ.)(DVDD/AVDD) |
| rohs: | |
| aplikazio | PND |
