| PartZenbakia | LQ050T5DG01 |
| Marka | SHARP |
| Tamaina | 5.0 |
| Aplikazio | CNS |
| Ebazpena | 400×240 |
| Konposizioa | LCM |
| Distira | 600 |
| CR | 800:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | SHARP |
| panel eredua | LQ050T5DG01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.0 inch |
| ebazpena | 400(RGB)×240 , WQVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 108×64.8 mm |
| eskema | 120.6×75.2×16.8 mm |
| azalera | Antiglare |
| distira | 600 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193150% |
| erantzun denbora | 35 (Typ.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4S2PWLEDWithout Driver |
| seinale interfazea | CMOS (1 ch, 6-bit), 40 pins |
| sarrerako tentsioa | 3.3/9.0V (Typ.)(VCC/VDC) |
| aplikazio | CNS |
