| PartZenbakia | LC230WX3-SLA1 |
| Marka | LG Display |
| Tamaina | 23.0 |
| Aplikazio | LCTV |
| Ebazpena | 1366×768 |
| Konposizioa | LCM |
| Distira | 450 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | LG.Philips LCD |
| panel eredua | LC230WX3-SLA1 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 23.0 inch |
| ebazpena | 1366(RGB)×768 , WXGA |
| bistaratzeko modua | S-IPS, Normally Black, Transmissive |
| eremu aktiboa | 508.152×285.696 mm |
| eskema | 546×318.3 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit) |
| erantzun denbora | 9/9 (Typ.)(Tr/Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6 pcsCCFLEmbedded (Inverter) |
| seinale interfazea | LVDS (1 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 12.0V (Typ.) |
| rohs: | |
| aplikazio | LCTV |
