| PartZenbakia | HV089WX1-100 |
| Marka | HYDIS |
| Tamaina | 8.9 |
| Aplikazio | PAD |
| Ebazpena | 1280×768 |
| Konposizioa | LCM |
| Distira | 300 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| panel marka | BOE HYDIS |
| panel eredua | HV089WX1-100 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 8.9 inch |
| ebazpena | 1280(RGB)×768 , WXGA |
| bistaratzeko modua | AFFS, Normally Black, Transmissive |
| eremu aktiboa | 193.92×116.352 mm |
| eskema | 224×133×5.25 mm |
| azalera | |
| distira | 300 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit) |
| erantzun denbora | 28 (Typ.)(Tr+Td) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 6S6PWLEDWithout Driver |
| seinale interfazea | LVDS (1 ch, 6-bit), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| aplikazio | PAD |
| A089SW01 V0 | AUO | 8.9 | 1024×600 |
| B089AW01 V0 | AUO | 8.9 | 1024×600 |
| B089AW01 V2 | AUO | 8.9 | 1024×600 |
| B089AW01 V3 | AUO | 8.9 | 1024×600 |
| HV089WU1-1E0 | HYDIS | 8.9 | 1920×1200 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LTL089CL02-W02 | Samsung | 8.9 | 1920×1200 |
| LTN089NT01 | Samsung | 8.9 | 1024×600 |
| N089L6-L03 | Innolux | 8.9 | 1024×600 |
| VVX09F035M20 | Panasonic | 8.9 | 1920×1200 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101UAN01.1 | AUO | 10.1 | 1920×1200 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| BP070WSA-400 | BOE | 7.0 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| LP094WX1-SLA2 | LG Display | 9.4 | 1280×800 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| LTN097QL01-A02 | Samsung | 9.7 | 2048×1536 |
| Q070LRE-LB1 | Innolux | 7.0 | 1024×600 |
