| PartZenbakia | HSD090LFW1-B00 |
| Marka | HannStar |
| Tamaina | 9.0 |
| Aplikazio | Automotive Display |
| Ebazpena | 1024×600 |
| Konposizioa | a-Si TFT-LCD, LCM |
| Distira | |
| CR | 800:1 |
| Koloreak | 262K/16.2M |
| Atzeko argia | WLED |
| Interfazea | LVDS |
| marka | HannStar |
| eredua | HSD090LFW1-B00 |
| diagonalaren tamaina | 9.0 inch |
| mota | a-Si TFT-LCD, LCM |
| pixel formatua | 1024(RGB)×600 [WSVGA] 132PPI |
| konfigurazioa | RGB Vertical Stripe |
| eremu aktiboa | 196.608(H)×114.15(V) mm |
| eskema dim. | 211.1(H)×126.5(V) ×6(D) mm |
| bezela eremua | 200.01(H)×117.55(V) mm |
| tratamendua | Glare (Haze 0%) |
| luminantzia | 450 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) (TM) |
| ikusi norabidea | Symmetry |
| erantzun denbora | 17/18 (Typ.)(Tr/Td) |
| ikuspegi angelua | 85/85/85/85 (Typ.)(CR≥10) |
| funtzionamendu modua | IPS Pro, Normally Black, Transmissive |
| euskarria kolorea | 262K/16.2M 50% NTSC |
| argi iturria | WLED , 150K hours , W/O Driver |
| pisua | 230g (Typ.) |
| entzat diseinatua | Automotive Display |
| fotograma-tasa | 60Hz |
| ukipen-panela | Without |
| interfaze mota | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| energia hornidura | 3.3/12.5/23/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| ingurunea | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
