| PartZenbakia | HSD100IFW1-C01 |
| Marka | HannStar |
| Tamaina | 10.1 |
| Aplikazio | DPF |
| Ebazpena | 1024×600 |
| Konposizioa | LCM |
| Distira | 250 |
| CR | 500:1 |
| Koloreak | 262K |
| Atzeko argia | WLED |
| Interfazea | TTL |
| panel marka | HannStar |
| panel eredua | HSD100IFW1-C01 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 10.1 inch |
| ebazpena | 1024(RGB)×600 , WSVGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 220.416×129.15 mm |
| eskema | 235×145.8 mm |
| azalera | Antiglare, Hard coating (3H) |
| distira | 250 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193147% |
| erantzun denbora | 5/20 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lanpara mota | 3S10PWLEDWithout Driver |
| seinale interfazea | TTL (1 ch, 6-bit), 60 pins |
| sarrerako tentsioa | 3.3/9.48/15/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikazio | DPF |
