| PartZenbakia | H546TAN01.0 |
| Marka | AUO |
| Tamaina | 5.5 |
| Aplikazio | MPH |
| Ebazpena | 720×1280 |
| Konposizioa | LCM |
| Distira | 440 |
| CR | 800:1 |
| Koloreak | 16.7M |
| Atzeko argia | WLED |
| Interfazea | MIPI |
| panel marka | AUO |
| panel eredua | H546TAN01.0 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 5.5 inch |
| ebazpena | 720(RGB)×1280 , WXGA |
| bistaratzeko modua | AHVA, Normally Black, Transmissive |
| eremu aktiboa | 68.04×120.96 mm |
| eskema | 72.3×130.39×1.75 mm |
| azalera | |
| distira | 440 cd/m² (Typ.) |
| kontraste-erlazioa | 800:1 (Typ.) |
| bistaratzeko koloreak | 16.7M (8-bit), CIE193170% |
| erantzun denbora | 35 (Max.)(Tr+Td) |
| ikuspegi angelua | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | WLEDWithout Driver |
| seinale interfazea | MIPI (4 data lanes) |
| sarrerako tentsioa | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| aplikazio | MPH |
