| PartZenbakia | G170HAN01.0 |
| Marka | AUO |
| Tamaina | 17.0 |
| Aplikazio | Industrial |
| Ebazpena | 1920×1920 |
| Konposizioa | a-Si TFT-LCD , LCM |
| Distira | |
| CR | 1000:1 |
| Koloreak | 16.7M |
| Atzeko argia | 9S6P |
| Interfazea | |
| panel marka | AUO |
| panelaren tamaina | 17.0" |
| ebazpena | 1920(RGB)×1920, 159PPI |
| bistaratzeko eremua | 305.28(W)×305.28(H) mm |
| eskema tamaina | 325.01(W)×319.33(H) ×12.2(D) mm |
| distira | 600 cd/m² (Typ.) |
| ikuspegi angelua | 89/89/89/89 (Typ.)(CR≥10) |
| ikuspegirik onena | Symmetry |
| bistaratzeko koloreak | 16.7M 72% NTSC |
| maiztasuna | 60Hz |
| pisua | 1.20Kgs (Max.) |
| panel eredua | G170HAN01.0 |
| panel mota | a-Si TFT-LCD , LCM |
| pixel formatua | RGB Vertical Stripe |
| bezela irekidura | - |
| azalera | Antiglare, Hard coating (3H) |
| kontraste-erlazioa | 1000:1 (Typ.) (TM) |
| bistaratzeko modua | AHVA, Normally Black, Transmissive |
| erantzun denbora | 13/12 (Typ.)(Tr/Td) |
| lanpara mota | 9S6P WLED , 50K hours , With LED Driver |
| pantaila taktila | Without |
| aplikazio | Industrial |
