| PartZenbakia | LQ170M1LA4B |
| Marka | SHARP |
| Tamaina | 17.0 |
| Aplikazio | NBPC |
| Ebazpena | 1920×1200 |
| Konposizioa | LCM |
| Distira | 340 |
| CR | 450:1 |
| Koloreak | 262K |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | SHARP |
| panel eredua | LQ170M1LA4B 1 Compatible model |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.0 inch |
| ebazpena | 1920(RGB)×1200 , WUXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 365.76×228.6 mm |
| eskema | 382.2×248×7 mm |
| forma estiloa | Wedge (PCBA Bent, Depth ≥5.2mm) |
| azalera | Glare (Haze 0%), Hard coating (2H), Antireflection |
| distira | 340 cd/m² (Typ.) |
| kontraste-erlazioa | 450:1 (Typ.) |
| bistaratzeko koloreak | 262K (6-bit), CIE193172% |
| erantzun denbora | 30 (Typ.)(Tr+Td) |
| ikuspegi angelua | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 2 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (2 ch, 6-bit), 30 pins |
| sarrerako tentsioa | 3.3V (Typ.) |
| rohs: | |
| aplikazio | NBPC |
