| PartZenbakia | QD17EL07 Rev.09 |
| Marka | QDI |
| Tamaina | 17.0 |
| Aplikazio | DMPC |
| Ebazpena | 1280×1024 |
| Konposizioa | LCM |
| Distira | 260 |
| CR | 500:1 |
| Koloreak | 16.2M |
| Atzeko argia | CCFL |
| Interfazea | LVDS |
| panel marka | QDI |
| panel eredua | QD17EL07 Rev.09 |
| panel mota | a-Si TFT-LCD , LCM |
| panelaren tamaina | 17.0 inch |
| ebazpena | 1280(RGB)×1024 , SXGA |
| bistaratzeko modua | TN, Normally White, Transmissive |
| eremu aktiboa | 337.92×270.336 mm |
| eskema | 358.5×296.5 mm |
| azalera | Antiglare, Hard coating (3H), Reflection 5.0% (Max.) |
| distira | 260 cd/m² (Typ.) |
| kontraste-erlazioa | 500:1 (Typ.) |
| bistaratzeko koloreak | 16.2M (6-bit + FRC) |
| erantzun denbora | 2/6 (Typ.)(Tr/Td) |
| ikuspegi angelua | 70/70/65/60 (Typ.)(CR≥10)(L/R/U/D) |
| maiztasuna | 60Hz |
| lanpara mota | 4 pcsCCFLWithout Driver |
| seinale interfazea | LVDS (2 ch, 8-bit), 30 pins |
| sarrerako tentsioa | 5.0V (Typ.) |
| aplikazio | DMPC |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| CLAA170EA10 | CPT | 17.0 | 1280×1024 |
| LB170E01-SL01 | LG Display | 17.0 | 1280×1024 |
| LC170WXN-SAA1 | LG Display | 17.0 | 1366×768 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LTN170X2-L03 | Samsung | 17.0 | 1440×900 |
| M170EG01 VD | AUO | 17.0 | 1280×1024 |
| M170EU01 V0 | AUO | 17.0 | 1280×1024 |
| QD17EL07 Rev.09 | QDI | 17.0 | 1280×1024 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| LM200WD1-TLD1 | LG Display | 20.0 | 1600×900 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLD1 | LG Display | 21.5 | 1920×1080 |
| LM240WU6-SDA1 | LG Display | 24.0 | 1920×1200 |
| LM270WF2-TLA5 | LG Display | 27.0 | 1920×1080 |
| M170EG01 V8 | AUO | 17.0 | 1280×1024 |
| M190E5-L0G | Innolux | 19.0 | 1280×1024 |
| M215HTN01.0 | AUO | 21.5 | 1920×1080 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
